Video: Charlie by Camp Dark

About six weeks ago I had a couple of sessions at Bellows Studio in St. Paul, Minnesota recording synthesizers for an upcoming record by Camp Dark. The project is headed up by producer Graham O’Brien and singer-songwriter Adam Svec. Graham and I have worked together on a variety of projects since 2007. One of those projects is Coloring Time, of which Adam is also a member.

10899032_752975858123761_972261083_n

It was a pleasure working on the record. Graham and Adam’s ideas are modern, distinct, and organic without ever being forced or unnatural. Their approach gave me the opportunity to use some of my favorites instruments, like the Moog Sub 37, alongside a few gems that rarely leave my studio. These included the Roland MKS-80, Yamaha FS1r, and (as featured on Charlie) the Roland Juno-106. Here’s a few words from the video’s description:

Charlie was written as an epilogue to a ‘Christmas Card From a Hooker in Minneapolis’ by Tom Waits. It’s a continuation of a story about the wanderlust of youth leading to dangerous things, and the associated regrets, coupled with an overwhelming homesickness for what’s been left behind … Video edited by local filmmaker / editor John Burgess. Footage used c/o Prelinger Archives: “Radiotherapy: High Dosage Treatment” & “Is This Love?” Written by Adam Svec & Graham O’Brien. Lyrics by Adam Svec. Produced by Graham O’Brien. Samplers & Drums by Graham O’Brien, Synths by John Keston, Bass Guitar by Casey O’Brien, Guitar by Matt Leavitt, Omnichord and Guitar Solo by Chris Salter.

Charlie is the first single from the Camp Dark album, Nightmare In A Day, which will be released on May 12, 2015 and is available for pre-order immediately at campdark.bandcamp.com. I’ll be joining Adam, Graham, and a few other musicians to perform renditions of tracks from the album at the Icehouse, in Minneapolis on May 15, 2015. For more credits, information, and details about the release show, please visit campdark.bandcamp.com.

March of the Robot Field Mice

a5c8e400950611e2ba6922000a1fb733_7

Here’s another “straight-to-tape-no-overdubs” track. This time I gave myself the liberty of pre-recording a few MIDI loops in the DAW with the mutes routed to a MIDI controller. I used eight of my favorite instruments including the Rhodes, Roland D-50, Roland Juno-106, Roland MKS-80, Korg Volca Keys, Novation Bass Station II, and SCI Pro-One.

Incidentally, the title of this track was inspired by a comment on Japan, California, UK that reads: “If, within 6 months, this isn’t the soundtrack to an inspirational, animated montage where cartoon field mice build an aeroplane from junk and fly above their home waving down to their friends, then there’s no justice.”

Japan, California, UK

9097915e6ffc11e39e520eb05158b030_8

Here is another no-overdubbing, straight-to-tape, composition using four of my favorite synths. The Yamaha FS1R provided the brittle, sustained, chord pattern. The Tempest handled the synth bass. The Bass Station II produced the arpeggio. Finally, I used the mighty MKS-80 for the lead playing. BTW: I took the photo in Seattle.

Synth Wall Mix #4

Here’s another offering from experiments concocted in my studio. I created this piece with no overdubbing. All tracks were recorded simultaneously. Post-production was limited to editing for length, fades, and one reverb send.

Low Latency Wired MIDI with iPad, Bitstream 3X, and QuNexus

Like many of you I have experimented with MIDI over wifi on the iPad. Mainly so that I can use a proper keyboard to play some of the splendid virtual instruments available on iOS. However, connecting to the iPad this way requires a computer on the same network, or instantiating an ad hoc network for the MIDI I/O. Secondly, although it can be stable it is usually slower and suffers from wireless network traffic congestion, hence more latency than a wired connection.

So what are the options? Over at CDM there’s a really great article from Nicolas Bougaïeff, the creative director at Liine (makers of the Lemur app and LiveControl) that explores a wide range of possibilities. Here my intent is to share what I have found works for me with a minimal investment in iOS specific hardware. Specifically, the Camera Connection Kit (CCK). The CCK essentially provides USB I/O for the iPad allowing class compliant MIDI devices to be connected and used. This works great, if you have such a device and all you want to do is use a hardware controller with the iPad.

The problem with the CCK is three fold – integration into more complex MIDI setups, class compliance, and power restrictions. Most USB MIDI devices only have a single USB port, so you can’t have a computer connected to the same controller to record the MIDI, or otherwise interface with iPad apps. As a result, two MIDI interfaces are required – one for the iPad and another for the computer for wired communications between them to be possible.

Secondly, many iOS hardware solutions are costly and impractical especially if you’d rather make use of equipment that most experienced producers have already invested in. Hardware that could work perfectly if only there were drivers available for iOS (I can dream, right?). One of my MIDI keyboard controllers, for example, is not class compliant over USB (an admittedly crappy CME UF7).

Third, beyond Apple’s sandboxing of iOS, even if your device is class compliant, they have set a very low limit on the power draw (10-100mA) often causing an annoying error to come up stating “The connected device requires too much power.” Fortunately there’s a hack/workaround for this problem. Simply attaching an unpowered USB hub between the CCK and your MIDI controller prevents the error from popping up and allows you to use your class compliant hardware. As an added benefit, the USB hub allows you to use multiple devices with your iOS device as long as they are either powered on their own, or they can draw enough power from the iPad/iPod Touch/iPhone. Side note: this works on iOS 6, but I do not know if it works on iOS 7 since I’m still waiting to do the update, so I’d love to hear from someone who has tried this.

Lately I have been researching potential solutions, and digging through my old MIDI hardware to see what kind of setup will work the best for me take to advantage of my favorite iOS music apps. Recently the thought occurred to me that perhaps I could use the Bitstream 3X MIDI controller (BS3X) with the iPad. I bought the BS3X back in the Spring of 2011 specifically to use as a controller for my Roland Super Jupiter MKS-80 analog synth, and therefore it is consistently available in my studio setup.

The BS3X is one of the most flexible and programmable MIDI controllers ever designed. It has traditional MIDI I/O including an in, two outs, and a thru jack. It’s even got a pre-MIDI Sync-24 jack. More importantly to this conversation is that is has class compliant USB MIDI I/O. The BS3X is designed to be an interface and controller in one and works perfectly to bridge my old hardware, iPad, and MacBook Pro together. Since everything is wired there’s little to no noticeable latency when playing a synth app with any MIDI keyboard plugged into the BS3X. Also, thanks to the plethora of I/O options on the BS3X, I can use the iPad and a collection hardware controllers (including my non-class compliant devices) with or without a computer in the chain. Furthermore integrating the iPad into this setup does not interfere with BS3X controlling the Roland MKS-80 because those controls send system exclusive messages (sysex) to the channel I have dedicated to the MKS-80.

In the video I have focused on illustrating how one might use two iPad synthesizer apps and a hardware synthesizer together including Cassini, Sunrizer, and the MKS-80. The BS3X is used as both the iPad interface and MKS-80 controller. No computer is required, but a simple change of cable allows for a computer to be integrated into this setup because the MOTU UltraLite interface and standalone mixer has MIDI I/O. In other words two MIDI interfaces are still necessary with a computer, but prior to this experiment I was only using the BS3X as a controller for the MKS-80 and bypassing the class compliant USB MIDI interface functionality. Since the USB hub was required I also added the QuNexus to the setup. This was dedicated to feeding notes into the arpeggiator in Cassini. The keyboard controller was split so that in the low end I could play the MKS-80 effect then tweak it with the BS3X knobs and sliders as it decayed. In the upper end of the same keyboard I played a lead sound programmed in Sunrizer.
