Using Tidal to Control the Roland System-1M

Roland System-1M

This is Mike Hodnick with my first article on I recently added the Roland System-1M semi-modular synth to my studio and live setups recently, and as with any new instrument in my studio I wanted to take it to extremes and see what it could do. It was the perfect occasion to document on!

I’m not your typical producer or performer. I write computer code, often improvised, to produce sound both live and in the studio. I use a language and live-coding environment called Tidal to trigger samples, play MIDI devices, and create sequences. Instead of a DAW or sequencer to create sound, I use a text language.

My first real experiment with the System-1M was to automate all of its MIDI Control Change parameters from code simultaneously. It’s kind of like running a few dozen LFO’s at once. I like to do this with all of my instruments to take them to an extreme and maybe even get some interesting sounds out.  As an added twist, I thought it would be fun to also live-patch the modular inputs and outputs on the System-1M while the MIDI automation was taking place. Here is the result:

The source code used for this performance experiment is at the bottom of this post. The only parameters that were not automated in this example were the Oscillator 1 level (kept at 100%), the Mono/Poly toggle (kept on Monophonic), Legato toggle (off), amp crusher (off), and LFO key retrigger (off). Details about the System-1M’s MIDI implementation can be found at

There are some brilliant sounds coming out of this thing!

By far, my favorite features of this synth are the two oscillators and their controls. Each oscillator supports multiple wave forms, modulation control (oscillator 2 can be ring-modulated from oscillator 1, and oscillator 1 can be cross-modulated from oscillator 2), and a “color” parameter which can be modulated from the LFO or filter/amplitude envelopes. Oscillator 2 also has a fine-tune control. With all of these combined, the possibilities are enormous.

Stay connected at, @kindohm or for info about Mike’s studio experiments, releases, and performances.

Here’s the source code used to control the System-1M:

-- play a m9 arpeggio, starting from MIDI notes 45, 33, or 57
m $ slow 2 $ (|+| note "[45 33 57]*4") $ mel m9 10 "0*16?"
|+| dur (scale 0.05 0.2 $ slow 1.9666 sine1)
|+| rlpcutoff (scale 0 1 $ density 1.01 sine1)
|+| rhpcutoff (scale 0 1 $ density 1.132 sine1)
|+| rfilteratk (scale 0 0.5 $ slow 1.2 sine1)
|+| rfilterdecay (scale 0.05 0.5 $ density 1.5181 sine1)
|+| rfiltersustain (scale 0.1 1 $ density 1.277777 sine1)
|+| rfilterrelease (scale 0.05 0.5 $ slow 1.523 sine1)
|+| rres (scale 0 0.7 $ density 1.313 sine1)
|+| rfilterenv (scale 0.1 0.9 $ density 1.111 sine1)
|+| rcrush "0"
|+| rampatk (scale 0 0.5 $ slow 1.213 sine1)
|+| rampdecay (scale 0.05 0.7 $ density 1.333 sine1)
|+| rampsustain (scale 0 1 $ slow 2.313 sine1)
|+| ramprelease (scale 0.05 0.3 $ slow 2.877 sine1)
|+| rpitchenv (scale 0.2 0.8 $ density 1.987 sine1)
|+| rport (scale 0 0.5 $ slow 1.77777 sine1)
|+| rpitchatk (scale 0 0.5 $ density 3.4111 sine1)
|+| rpitchdecay (scale 0 0.5 $ density 1.2222 sine1)
|+| rosc1 "1"
|+| rosc2 (scale 0 1 $ slow 2.6665 sine1)
|+| rosc2tune (scale 0.2 0.8 $ slow 3 sine1
|+| rsub (scale 0 1 $ slow 1.919 sine1)
|+| rnoise (scale 0 1 $ density 3.71771 sine1)
|+| rnoisetype "[0 1]*3"
|+| rsubtype "[0 1]*5"
|+| rlegato "0"
|+| rmono "0.5"
|+| rosc1type (scale 0 1 $ slow 1.77777 sine1)
|+| rosc1range (scale 0 1 $ slow 2.8888 sine1)
|+| rosc1color (scale 0 1 $ density 1.4344 sine1)
|+| rosc1xmod (scale 0 1 $ density 1.30010010 sine1)
|+| rosc1mod (scale 0 1 $ density 3 sine1)
|+| rosc2type (scale 0 1 $ slow 0.9999 sine1)
|+| rosc2range (scale 0 1 $ slow 3.151 sine1)
|+| rosc2color (scale 0 1 $ slow 5.131 sine1)
|+| rosc2ring "[0 1]*9"
|+| rosc2mod (scale 0 1 $ slow 3.141 sine1)
|+| rosc2sync "[0 1]*7"
|+| rlforate (scale 0 1 $ slow 2.17717 sine1)
|+| rlfofilter (scale 0 1 $ slow 3.3333 sine1)
|+| rlfoamp (scale 0 1 $ slow 1.21 sine1)
|+| rlfotype rand
|+| rlfokeytrig "0"
|+| rdelay (scale 0 1 $ sine1)
|+| rdelaytime (scale 0 1 $ slow 3.888 sine1)
|+| rreverb (scale 0 0.4 $ density 1.2331121 sine1)
